2027 Kearney 5 X 10 UTB – Single Axle Pipetop, Gated - 068447

COUPLER: 2" - 7K Ram W/Coupler Hole Cover Plate

■ SAFETY CHAIN: 1/4" Chain W/Safety Hooks

■ JACK: 2K Top Wind W/Interchangeable Pin-On Sand Foot, Jack Is Set Back For Tailgate Opening Clearance

■ PLUG: 4 - Way Molded Plug Harness / Grounded To Frame

■ LIGHTS: "LED" Rubber Mounted Running, Stop, Turn & Clearance

■ FENDERS: 9" X 32" Rolled Smooth W/Smooth Backing Plates

■ SUSPENSION: 4-Leaf Eye-To-Eye Springs System

■ AXLES: One - 3.5K Dexter Idler / Cambered W/Accu-Lube Hubs

■ TIRES: New ST-205-75-R-15" Radials Load Range "C" 6-Ply

■ WHEELS: 5-Hole Powder-Coated Silver Mods / GM-5"-BP

■ TONGUE: 5'X 12' & Smaller - 3" X 2" X 3/16" Angle Iron, 5'X 1д' 8 All 77" & 93" Wides - 4" Channel Iron

■ FRAME: 3" X 2" X 3/16" Angle Iron

■ CROSS MEMBERS: 3" X 2" X 3/16" Angle Iron

■ UPRIGHTS: 2" X 2" X 1/8" Angle Iron

■ TOP RAIL: 2" X 2" X 1/8" Angle Iron Sq-Ends W/Board Holders

■ FLOOR: #1 Pres Treated/2"X8" Pine Double Screwed/Per/Run

■ TIE DOWNS: Four - Stake Pockets One On Each Corner

■ STICKERS: Warning & Safety & Reflective Kearney Logos

■ EXT. FINISH: Painted With A Newly Innovated Durable High Gloss Acrylic Polyurethane Full Two-Component Finish

■ TOP UNDERCOATING: Completely Coated w/A Durable Protective Finish

■ TRIM: Array of many colors to choose from
